Madox Machines is a company that manufactures all chips production lines and advanced packaging systems. Madox Company relies in its industries on advanced technology as it offers products of high European quality that give it a strong position in the global markets. Madox was founded in 1991 in the industrial zone of the Syrian city of Aleppo by the Syrian businessman Sobhi Riad Natour, then the company moved to the Turkish city of Gaziantep in 2013 with the aim of expanding the business. Madox worked in the manufacture and development of the first extruder for the manufacture of corn chips in the Middle East in its first launch in 1991, then began to develop integrated systems competing for major international companies. On the level of packaging systems, Madox had a distinguished and impressive position in the global markets, as it provided the best and most advanced packaging machine in the world. All of our products are made with the best and finest raw materials that have been carefully selected for this purpose the field. Madox has been located in the Turkish city of Gaziantep, in the industrial zone, since 2013 to this day. Maddox exports its products to all countries of the world, and it has a flexible system in this regard that allows it to provide a distinguished service to all its customers.

Stuffed corn production line MDX/SC250

Stuffed corn production line MDX/SC250

Stuffed corn production line MDX/SC250

Stuffed corn production line MDX/SC250 Turkish made, European quality, equipped with safety systems and saving systems.

Main Features of Corn Chips Production Line:
  • Model MDX/SC250
  • Capacity 250 kg/h.s
  • Automatic production line made of stainless steel
  • In addition, it is made of stainless steel 304 .
  • American high-tech and quality system.
Corn snack production line consists of:
  1. Corn Mixer
  2. Screw feeder for extruder
  3. Extruder (automatic feeder with blasting machine) (signel screw)
  4. conveyor belt
  5. Drying Oven
  6. Cooling BAND (after oven)
  7. Chocolate cooking and processing set
  8. Control panel
1_Corn Mixer:
  • Capacity 450 kg
  • Made of stainless steel (Stainless Steel 304)
  • It is equipped with a small window to see the level of material inside.
  • Mechanical protection to prevent worker’s hand from entering the mixer. (Metal cage)
  • Working while cleaning is equipped with electrical protection to protect staff’s hand.
  • It is a system developed to remove metal impurities in corn.
  • Equipped with water tank for humidification.
  • Engine Turkish made Volt brand power 4 kW.
2_Screw feeder for extruder:
  • Screw feeder for extruder, Made of 304 stainless steel
  • A window was created from the bottom to facilitate cleaning.
  • Extruder supplies the main raw material to be used
  • Equipped with electrical protection to protect the hands of working personnel during cleaning.
  • It is a system developed to remove metal impurities in corn.
  • Engine made in Turkey Volt brand power 0.75kw.
3_Extruder (automatic feeder with blasting machine) (signel screw):
  • Extruder, American Model
  • The extruder is fed automatically.
  • The motor is very powerful / 41.25KW /
  • It is controlled by an inverter.
  • The redactor is made of the finest types of metal that carry the pressure of working hours.
  • Balls Swedish or German made SKF brand
  • Extruder shaft is made of steel that has been treated with the latest bending method.
  • Spirals are made of the highest quality metals.
  • 2 spirals are attached with the line.
  • Extruders motors are electronically controlled by an inverter.
  • Equipped with an electronically controlled heating device (Heat clock).
  • All Extruder operations are controlled by a main control panel.
  • Independent of the extruder structure, it is equipped with two ventilation fans.
  • The extruder is equipped with water cooling (closed circuit) and air cooling.
  • Chrome wrapped externally to facilitate the cleaning process.
4 _ conveyor belt:
  • Its function is to transfer the products produced from the extruder to the drying oven.
  • The structure is made of chrome.
  • The engine is equipped with power (0.75 KW).
5_ Drying Oven:
  • It works with Diesel and Electric.
  • Length 6 m
  • Width 170 cm
  • height 220 cm
  • It saves more than 60% energy due to the added Advanced technology.
  • Tasks are controlled by a Plc screen.
  • Its capacity is 37.5 kW.
6 _ Cooling BAND (after oven):
  • Length 4 meters
  • motor capacity 0.75 kW.
7 _ Chocolate baking and processing set:
  1. Chocolate cooking tank capacity 500 kg, engine power 7.5 kW Made of stainless steel 304 floor thickness 18mm, wall thickness 10 mm Equipped with double jacket and special chocolate pump, power 1.5 kW.
  2. Ready chocolate tank and pumping stage capacity 500kg, engine power 4 kW
  3. and equipped with a special chocolate pump, power 1.5 kW.
8_Control panel:
  • Motors from volt brand
  • Gearboxes NRW German brand
  • Contactor thermal protection circuit breakers – engine breakers are from the famous German company Eaton
  • Inverters from Fuji, Japan
  • The line is made And laminated with SS
  • Additional information:
  • We offer a two-year warranty from the date of delivery.
  • All of our products are CE certified.
  • And İSO 9001:2015,  İSO 45001:2018 certificates.
  • Above all, we are keen on the customer’s peace of mind and reassurance before the purchase process and similarly after the purchase process.
  • We provide all technical, logistical and technical support during production, for example: technical information, chips mixes, chips flavor mixes, and spare parts.
