Madox Machines is a company that manufactures all production lines of half-fried (frozen) potatoes, natural chips, snacks and advanced packaging systems. Madox Company relies on technology developed in its industries, as it offers high European quality products that give it a strong position in global markets.

French fries production line MDX/FF700

French fries production line MDX/FF700

French fries production line MDX/FF700

Fully automatic French Fries Production Line 600kg/H to 700kg/h, high technology completely made of SS, Can produce flat and V Cut shape of fresh potato,

The half-fried potato production line (frozen potatoes) from Madox Company produces flat potato sticks. The production line for half-fried potatoes is equipped with the highest modern technologies. In addition to that, it is made of the finest industrial raw materials. The production line is also distinguished by its European quality and modern Turkish industry.

Through this page, you will be able to obtain a price quote and detailed specifications by contacting the marketing team. In addition, you can obtain a detailed feasibility study for the half-fried potato production line project.

Get a price quote ? click here

Explanation content:
  • Introduction about the French fries production line.
  • Classification and ranking of the basic features of the half-fried potato production line.
  • List the configuration and machinery of the production line.
  • Detailed explanation of the half-fried (french fires) potato production line.
  • Additional Information (Quality Certificates).
  • Quotation request form.

Main Features of French fries production line MDX/FF700:

  • Fully automatic French fries production line
  • French fries production line high technology
  • French fries production line completely made of Stainless Steel
  • European quality, Turkish made
French fries production line consists of:
  1. Potato tank and conveyor
  2. Potatoes Washing machine
  3. Potatoes Peeling machine (french fries)
  4. Check conveyor belt
  5. Conveyor belt to slicer machine
  6. Potatoes cutting machine (Special for french fries)
  7. Rinsing and conveyor belt
  8. Blanching machine
  9. Potato dryer machine
  10. Dryer belt
  11. Frying machine (french fries fryer)
  12. Deoiling machine
  13. Check and cooling conveyor belt
  14. control panel
Detailed explanation of French fries production line:
1_ Potato tank and conveyor
  • Function: collecting the potato granules in a tank, soaking them, and then preparing them for the washing pump.
  • Metal: SS304.
  • Engine: 2 hp from Siemens, Germany, with an NRW gearbox, a German franchise.
2_ Potatoes Washing machine
  • Function: The first stage of washing the potato granules, whereby washing and removing the dust that is attached to the potato granules.
  • Metal: SS304.
  • Equipped with a Siemens 2 HP engine from an NRW gearbox.
  • It is also equipped with a 3-horsepower Siemens engine with an NRW gearbox.
3_  Potatoes Peeling machine (french fries)
  • Function: Peeling potatoes as required.
  • A very high technology as it only removes the peels without any waste from the potato.
  • Metal:SS304
  • Equipped with a Siemens 2 HP engine from an NRW gearbox.
  • Equipped with a Siemens 3 HP engine with NRW gearbox
4_  Check conveyor belt
  • Function: Watching the peeled potatoes and picking out the bad ones.
  • Its task is to transfer the potatoes from the peeling stage to the cutting stage on a conveyor belt that stirs the potato grains to be detected on the lower side by the mechanism of rotating each potato.
  • Metal: SS304.
  • Fitted with a 1 HP Siemens engine from an NRW gearbox.
5_  Conveyor belt to slicer machine
  • Function: Transfer the potato kernels to the slicing machine.
  • And a 1 hp Siemens engine from an NRW gearbox.
  • Metal: SS304.
6_  Potatoes cutting machine (Special for french fries)
  • Function: Cut the potatoes as desired .. Potato fingers and zikzak fingers.
  • In addition, a thickness gauge stabilization mechanism has been added (Madox’s own).
  • Equipped with a 2 hp engine.
7_  Rinsing and conveyor belt
  • Function: Extra washing stage for potato.
  • Equipped with a Siemens 2 HP engine from an NRW gearbox.
  • Equipped with an Italian brand water pump with a capacity of 1 hp.
8_  French fries Blanching machine
  • Function: pulling out the starch, adjusting the sugar, and then blanching the potato.
  • The 2-hp Siemens engine was powered by an NRW gearbox.
  • And a 1 hp Siemens engine from an NRW gearbox.
  • Equipped with an Italian brand water pump.
  • It is equipped with a 3-horsepower engine, the German Siemens brand.
  • Also equipped with a 3-horsepower engine, the German Siemens brand.
  • In addition to a tank for water treatment.
9_  Potato dryer machine
  • Function: Dry the flakes from the water.
  • Equipped with a 1 horsepower Siemens engine with a gearbox number: 3.
  • In addition, it is accompanied by special drying fans with a capacity of 4.05kw.
10_ Dryer belt
  • Function: Extra drying stage:
  • Equipped with a 1 HP Siemens motor.
11_ Frying machine (french fries)
  • Function: Fry the potatoes according to a certain standard.
  • The potato frying machine is very advanced.
  • It works with two different frying systems combined together, ensuring that the potatoes are fried perfectly evenly and with high quality.
  • The fryers operate on gas or diesel as per customer request.
  • Precise temperature setting.
  • Five-stage filtration, filtration capacity is 8000 liters per hour.
  • Equipped with two oil compensation tanks, each tank has a capacity of 900 liters, insulated with a double jacket.
  • Compensation and filtration are fully automatic (vacuum filtration circuit 5 stage MESH KROM graduated).
  • 2 HP Siemens engine with NRW gearbox.
  • 1 HP Siemens engine with NRW gearbox.
  • High temperature oil pump plus 3 HP motor for filter assembly.
  • And a special high-temperature oil pump in addition to a 2-hp engine.
  • In addition, it is equipped with an Italian burner brand R?ELLO, BALTUR or ECOFLAM.
  • Also a fire safety system.
  • And a system to control the passage of potato per second within the frying machine (advanced system).
12_ Deoiling machine
  • Function: extracting oil from potato.
  • It is made of stainless steel and in addition to that it is laminated with stainless steel.
  • Equipped with two VEBRATOR motors, power 300w * 2, AVABRO brand specialized in the manufacture of bottles.
13_ French fries Check and cooling conveyor belt
  • Function: Examination and purification of potato, which leads to raising the quality of the product, in other words, it gives us a competitive product in the market.
  • 1 HP German Siemens engine with NRW gearbox.
14_ French fries production line control panel
  • Motors from the famous German company Siemens
  • NRW gearboxes German brand
  • Contactor thermal protection circuit breakers – engine breakers are from the famous German company Eaton
  • PLC control screen from the famous German company Siemens
  • Inverters from Fuji, Japan
  • The line is made And laminated with Stainless Steel,
Stunning and freezing stage:
  • This stage is one of the most important stages and is divided into several stages:
  • First: prepare the potatoes to enter the stun and freeze tunnel.
  • Second: The potatoes are electrocuted and frozen inside the tunnel for the half-fried potatoes:
  • The stunning and freezing tunnel is equipped with the latest equipment and is specially designed for demi-fried potatoes.
  • We also offer a guarantee for the product.
  • For more details, please contact the company.
Additional information:
  • We offer a two-year warranty from the date of delivery.
  • All of our products are CE certified.
  • And ?SO 9001:2015,  ?SO 45001:2018 certificates.
  • Above all, we are keen on the customer’s peace of mind and reassurance before the purchase process and similarly after the purchase process.
  • We provide all technical, logistical and technical support during production, for example: technical information, chips mixes, chips flavor mixes, and spare parts.
